Engine displacement is the volume, measured as the space between the top of the piston at bottom dead center (BDC) and top of the cylinder. The combustion chamber is in the head and is not part of this calculation.
This chart describes the engine displacement based on Bore and Stroke.
- Measurements are in millimeters (mm or mil).
- Bore is the diameter of the engine cylinder.
- Stroke length is the distance travelled by the piston during each cycle of the engine.
- Stroke is affected by the swing of the crankshaft during a rotation and the connecting rod length.
- Q - What is a 4 mil or 10 mil engine?
A - Stroke length is +4 millimeters or +10 mil over stock stroke of 54mm.
Keep scrolling to see some common engine builds below the chart.
